Parker 2 way stainless steel solenoid valve 220/240V 50/60Hz Dn2.5mm

On this page you will find a 3 way solenoid made by the parker company. The Parker part number used for this solenoid valve is 393430J This solenoid valve has a threaded in and outlet which are both 1/4” BSP-G. the exhaust valve is a 1/8” BSP-G thread which is conical. This specific valve has a 9W coil which is a 220/230V at 50/60Hz. The coil part number...

This valve body is made by the company Parker and it is a 3 way valve, with the part number PM128IV.5. The drain side is a 1/8”bsp-g thread and has a conical shape.  The plunger inside the coil is rated up to 20bar. This plunger is sealed of with a FKM gasket. This gasket seals off the central hole, orifice, which has a diameter of 1,3mm. The entire body...

The solenoid valve body on this page is made by the Italian company Parker and has the part reference number E131F4304G. This valve body is a 3 way valve. The valve itself has a central hole, orifice, of 1,5mm. This orifice is sealed off with a plunger with a ruby seal. This plunger is rated  up to 10 bar. This valve body is used on a variety of espresso...

This parker solenoid valve body is a 2 way valve made from stainless steel. This model is called the 2019F1LVG7. This version has a orifice, central hole, which has a diameter of 2,5mm and is sealed of with a FKM seal. The valve is NSF certified.

On this page you will find a Parker 2 way solenoid valve. This solenoid valve can be used on Astoria (18159002), San Remo (10303093A) and Wega (WY18159002) water inlet valves. The Parker part number for this solenoid valve is 2019F1GRG7XS03XS6 This 2 way solenoid valve is of the new design, so no brass base but a stainless steel one which is NSF...

With a standard flange solenoid valve you only need 2 small o rings to seal this off, this is the case with brands such as Asco/sirai, Parker, Lucifer and Ode. But the brand Parker has also stainless steel solenoid valve, which use a o ring and a outer gasket, which is not a o ring. This type of gasket used on various espresso machine brands such as...

This solenoid valve body is a 2 way valve. This model is called 2019F1GRG7 and is made from stainless steel. The central hole in the valve has a diameter of 1,5mm and is sealed off with a small ruby in the plunger. The valve itself is rated up to 20 bar working pressure.

This solenoid valve body is made by the Parker brand. This body is made from stainless steel and NSF certified. The model is called the 2019F1LRG7 and this is a 2 way valve. The orifice, central hole, has a diameter of 2,5mm and is sealed of with a small ruby in the plunger. The valve body is rated up to 20bar working pressure.
